Chapters in Architectural Drawing

Hand Sketching in a Digital World

Published March 11, 2009
400 Pages
ISBN: 978-1-58503-495-6


Chapters in Architectural Drawing provides an introduction to the fundamental principles needed to create compelling freehand and hard line drawings. Using the graphics, instructions, sketching exercises, and the included videos the reader will learn the techniques used by architectural professionals to visually communicate ideas and create dramatic client presentations.

The content of this book is important to today's high-tech design industry. You will learn what role architectural hand drawing has today compared to cutting edge computer design and rendering software, and how the two can be leveraged to create crisp, clean sketches with an economy of time! Although you will not be expected to use any software to complete this book, you will be introduced to several methods in which these tools are used. In these exercises all the computer work has been prepared so you can focus solely on the sketching portion.

This book takes a unique approach to teaching these invaluable techniques. Throughout the book you will find video symbols. These symbols indicate that a short video pertaining to the subject can be found on the DVD included with each text. In these videos the authors discuss and clearly demonstrate how to perform the techniques described in the book.

Techniques you'll learn in this book:

  • Drawing views and scales
  • Architectural graphic symbols
  • Drawing diagrams, graphs and charts
  • One and two point perspective drawing
  • Still life drawing
  • Paraline drawing
  • Drawing people, cars and trees
  • Drawing reflections and shadows
  • Digital sketching
  • Computer model underlay
  • 2D presentation drawings

Table of Contents

  1. Introduction
  2. Views, Scales & Symbols
  3. Getting Started
  4. Formulating Design Solutions I
  5. Formulating Design Solutions II
  6. Still Life Drawing
  7. Paraline Drawing
  8. The Perspective: Two-Point I
  9. The Perspective: Two-Point II
  10. The Perspective: One-Point
  11. Entourage and Reflections
  12. Digital Sketching Techniques
  13. Computer Model Underlay
  14. Architect David Salmela FAIA
    Video Index


Exclusive Content

These files are only available to customers who have registered their book with the unique access code that comes with the book and authenticated instructors. Ebook owners can send us a proof of purchase to gain access to these files.

Video Instruction
Download disabled.
Videos Instruction with Captions
Download disabled.

For additional information on downloading, unzipping, and using these files visit the downloads section on our FAQ page.

More Information

Product Details

Published March 11, 2009
400 Pages
Binding: Paperback
Printing: Black and White
Print ISBN: 978-1-58503-495-6 | ISBN 10: 1585034959
eBook ISBN: 9781630563561
