Book Errata

Errata

Chapter 3 Page 35

Step 7. should ask you to Enter Extrudes_Exe1 for the file name.

Chapter 4 Page 18

Step 27. You should add the .032in. fillet to the 6 edges, as indicated in the image.

Chapter 4 Page 19

A step must be added before saving your work. The new step 28 should instruct you to add the .032in. chamfer to the 4 edges of the holes, as noted in the image. See the image below.

Chapter 5 Page 24

Step 8. should says to "Select the Cut-Revolve1, the Cut-Revolve2, the Fillet2, and Fillet3, either from the graphics or from the feature tree."

Chapter 10 Page 16

Step 3: Should direct you to add three (3) more instances of the first component into the assembly document.

Chapter 11 Page 13

Step 5. Under Enter the following: it should be 0deg for Start Angle and 90deg for Maximum.

Chapter 11 Page 22

Step 5. The description should say: Select the circular edge of the Upper Jaw and the circular edge of the Trigger.
