Book Errata
Engineering Graphics Essentials with AutoCAD 2023 Instruction
Text and Video Instruction
Published August 23, 2022
954 Pages
ISBN: 978-1-63057-519-9
- View Errata
- Submit Errata
Errata
The first printing of this book contains pages in which a font used for engineering symbols was not correctly rendered. You can download the corrected pages here.
- Chapter 2 Page 65
In the description box for "Creating a Path Array", step 1 should say to use the arraypath command.
- Chapter 8 Page 22
Steps 3. Create a new multileader style, sub steps d) and e), the images under these steps should show a size of 2.5, matching the corresponding text in the book. See the image below.
- Chapter 17 Page 36-39
Pages 17-36 through 17-39, all dimensions are in MM, not inches.
